Feishu bot + self-hosted AI service in 30 minutes (with 4 fix-or-it-fails moments)

From creating an enterprise app to receiving the first AI reply (with four fix-or-it-fails moments)

TL;DR — Open Feishu Open Platform → create a corporate self-built app → wire up the webhook → plug in your AI service → receive your first reply in IM. The last section lists four errors I hit on every first deploy, with the fix each time.

Step 1: create the Feishu app

📌 Corporate self-built app 5 min

Go to open.feishu.cn and sign in as your corporate admin
Developer console → Create "corporate self-built app" → fill in name / icon / intro
Copy the App ID and App Secret (you won't see the secret again)
Permissions → enable: im:message, im:message.group_at_msg, im:message.p2p_msg
Event subscriptions → add event im.message.receive_v1

Step 2: minimum echo webhook

🐍 Python Flask 30-line echo 5 min

Get connectivity working before you add AI:

from flask import Flask, request, jsonify

app = Flask(__name__)

@app.route("/webhook", methods=["POST"])
def webhook():
    data = request.json
    if data.get("type") == "url_verification":
        return jsonify({"challenge": data["challenge"]})

    event = data.get("header", {}).get("event_type")
    if event == "im.message.receive_v1":
        msg = data["event"]["message"]
        sender = msg["sender"]["sender_id"]["open_id"]
        text = msg["content"]["text"]
        reply_text = f"You said: {text}"
        send_message(sender, reply_text)

    return jsonify({"code": 0})

def send_message(receive_id, text):
    pass  # your existing send impl

if __name__ == "__main__":
    app.run(host="0.0.0.0", port=8080)

Step 3: expose it via ngrok

🌐 Public callback URL 2 min

Install ngrok (or bore / cloudflared)
ngrok http 8080
Paste the https://xxx.ngrok.io URL into Feishu Event Subscription → Request URL
Hit "Test connection" — you should see {"code": 0}

Step 4: replace echo with AI

🤖 Plug in your AI service 10 min

import requests

def ask_ai(prompt):
    resp = requests.post(
        "https://your-ai-service/api/chat",
        json={"message": prompt, "max_tokens": 1000},
        timeout=30
    )
    return resp.json()["reply"]

# Inside webhook():
reply_text = ask_ai(text)

Once stable, layer on:

Conversation memory (Redis by user_id)
Knowledge base retrieval (RAG before the LLM call)
Skill execution (drive the LLM with templates)

Step 5: ship a version

🚀 Publish 5 min

Feishu console → Version management → create v1.0.0
Release notes: "AI assistant internal beta, scope limited to specific users"
Submit for review → corporate admin approves
After approval: @ the bot in DM or group chat — first message lands

Four errors you will hit on the first run

Error 1: Feishu "Test connection" silently fails

URL verification sends {type: "url_verification", challenge: "..."} and expects the response to include challenge verbatim. Forget this branch and you get a generic failure with no clue.

✅ Always handle type == "url_verification" before business logic.

Error 2: 230001 (App Secret mismatch)

tenant_access_token needs App ID + App Secret. Typo in either and you see a generic "call failed" — no hint where.

✅ Store the secret in an environment variable, not in code. When you rotate, update code and config together.

Error 3: "Send succeeded" but no message in IM

Feishu distinguishes open_id, user_id, email, and chat_id. Mix them up and Feishu returns 200 with nothing delivered.

✅ For DMs use open_id, for groups use chat_id. Pick based on the inbound sender_id fields.

Error 4: rate limit 230020

Feishu's 100 QPS limit is per tenant. A 20-person group @-ing the bot simultaneously brushes past it.

✅ Add a token bucket (per tenant or per bot) in front of your AI service, cap around 80 QPS, return "let me check" when over budget rather than dropping silently.
